Typical Applications
The Dehnco Table Roll Stand bolts into any flat surface. The cantilever arms are available to hold roll diameters up to 48-inches.
Rolls mount onto removable roll bar. The bar rests in sturdy notches in the arm. The system is a low cost way to put roll material within easy reach.
Stands are ruggedly constructed for long life.
Components
| Part # | Description |
|---|---|
| TRSEC-3612 | max roll width 24" - max diameter 24" used with economy cutter EC-2436 |
| TRSEC-3624 | max roll width 24" - max diameter 48" used with economy cutter EC-2436 |
| TRSEC-4812 | max roll width 36" - max diameter 24" used with economy cutter EC-3648 |
| TRSEC-4824 | max roll width 36" - max diameter 48" used with economy cutter EC-3648 |
| TRSRC-4412 | max roll width 30" - max diameter 24" used with economy cutter RC-3044 |
| TRSRC-4424 | max roll width 30" - max diameter 48" used with economy cutter RC-3044 |
| TRSRC-5412 | max roll width 40" - max diameter 24" used with economy cutter RC-4054 |
| TRSRC-5424 | max roll width 40" - max diameter 48" used with economy cutter RC-4054 |
| TRSRC-6412 | max roll width 50" - max diameter 24" used with economy cutter RC-5064 |
| TRSRC-6424 | max roll width 50" - max diameter 48" used with economy cutter RC-5064 |
General Specifications
- The Table Roll Stand can be used with any Dehnco rotary shear/economy style cutter or as a stand alone system.
- The Dehnco Table Roll Stand will accommodate rolls of material up to 50" wide and up to 48" in diameter.
- Stand is constructed of formed metal components which supports up to 100 pounds. It can be mounte on any flat surface.
- The uprights of the Table Roll Stand are adjustable in height to allow the leading edge of the material to be at the most ergonomic position for the worker.
- Casters are available to make the wall roll stand stand portable.
